Jyetech DSO183 Diy Oscilloscope Kit 500Khz Adc Built In Signal Generator Waveform Display For Electronic Competition Tra

Specification Model DSO183Bandwidth 500KHzADC Precision 12BitReal time Sampling Rate 1 5MspsWaveform Memory Depth 1024 pointsVertical Sensitivity Range 10mV div 5V divInput Impedance 1MΩMaximum Input Voltage 50VpkCoupling Modes DC AC GNDHorizontal Base Range 1us div 500s divTrigger Modes Auto Normal SingleTrigger Edge 1us div 500s divWaveform Retention Function Yes1KHz 3 3V Test Signal YesSquare Waves Signal Generation YesSine Wave Signal Generation YesWaveform Storage Output Function YesWaveform Parameter Digital Display Yes supports display of maximum value minimum value peak value average value RMS value frequency period and duty cycleWaveform Retention Output Function YesPower Supply DC 5V USB Type C interface inputPower Consumption 100mADimensions 118 x 76 x 12 mm excluding front panel Weight 45g excluding front panel and probe cable Display Language English Chinese optionalNOTE This is a DIY kit you will need to solder and assemble Features 1 Improved Bandwidth Enhanced from 200 kHz previous model DSO138 to 500 kHz for reliable signal capturing 2 Built in Signal Generator Includes functionality to generate sine triangle and square waves signals for testing purposes 3 LCD Display Supports both English and Chinese menus for enhanced usability across different regions 4 Power Convenience Operates via USB Type C input eliminating the need for additional adapters 5 Compact and Stable Design Single board structure
