WB-SG1 8GHZ Wideband Signal Generator Dual Channel Rf Source Temperature Oscillator Ocxo 1Hz To 22Ghz Adjustable Output

Features 1 Wide Frequency Coverage Complete Model Range Offers an 8GHz wide frequency range to meet various application needs 2 Dual Channel Output CH1 for low frequency output CH2 for high frequency output with CH2 featuring on off modulation 3 High Precision Reference Built in OCXO temperature controlled crystal oscillator with an annual aging rate as low as 0 5ppm supports external 10MHz reference input 4 Portable and Compact Aluminum alloy casing weighing only 350 grams easy to carry Specifications Product Model WB SG1 8GHZFrequency Range CH1 1Hz 250MHzCH2 1Hz 6 4G 9 5G 15G 20G 22G depending on specific model Frequency Step CH2 1HzOutput Impedance 50ΩInterface Type SMA FemaleDimensions 106mm L 55mm H 105mm D Weight Approx 350gCH2 Reference Output Power Typical 1GHz Reference Value 5dBm to 7dBmTypical Output Power at Each Frequency 6G 8 5 dBm7G 4 5 dBm8G 5 2 dBm9G 4 4 dBm10G 3 4 dBm11G 4 3 dBm12G 4 6 dBm13G 3 0 dBm14G 3 0 dBm15G 1 7 dBm dBm16G 1 4 dBm17G 4 9 dBm18G 6 4 dBm19G 6 5 dBm20G 8 3 dBmInternal Reference and Time Base Internal Reference Frequency 10MHzReference Type Oven Operated Crystal Oscillator OCXO Annual Aging Rate ≤ 0 5ppmExternal Reference Supported External Frequency Standard Input Package Included 1 x WB SG1 8GHZ Signal Generator1 x DC12V Power Adapter EU Plug
