M5Stack M5Stamps3 BAT Module With Battery Connector ESP32-S3-PICO-1-N8R8 8MB Flash Psram 2.4Ghz Wi-Fi RGB LED Iot Develo

Specifications SoC ESP32 S3 PICO 1 N8R8 Dual core Xtensa LX7 processor main frequency up to 240MHzFlash 8MBPSRAM 8MBWi Fi 2 4 GHz Wi FiInput Power 3 7V battery power supply USB Type C DC 5VRGB LED 1 x WS2812Battery Interface SH1 0Pad GPIO Leads 11 x GPIO G1 G2 G3 G4 G5 G6 G7 G8 G9 G10 G11 1 x Wake up IO PY G4 WAKE BTB Interface GPIO Leads 19 x GPIO G40 G38 G12 G13 G14 G15 G16 G18 G21 G46 G45 G41 G43 G42 G39 G17 G44 G47 G48 BTB Connector BTB0 408 24PLBDR M41 12 2P FPC direct plug Black pitch 0 4mmAntenna Connector IPEX 4Battery Connector SH1 0 2PAntenna Type FPC AntennaOperating Temperature 0 40°CPower Consumption Sleep mode 4 2V 13 43uA Standby mode 4 2V 955 36uA Light load mode 4 2V 26 83mA Full load mode 4 2V 27 49mAProduct Size 29 8 x 18 0 x 5 5mmProduct Weight 3 6gIntroduction Stamp S3Bat is an embedded core module with integrated power management It uses the ESP32 S3 PICO 1 N8R8 as the main control core supporting 2 4GHz Wi Fi with built in 8MB Flash and 8MB PSRAM The module leads out a total of 11 GPIOs and 1 wake up IO and is equipped with a 24P BTB connector supporting DVP interface The onboard battery power interface is used for external 3 7V lithium battery power supply It features the built in M5MP1 multi level power control design supporting power input output control lithium battery charging management and status detection such as input voltage and battery voltage It also supports external low power wake up f
