M5Stack M5Stamp C6Lora Module ESP32-C6 SX1262 850-960Mhz 2.4Ghz Wi-Fi 6 Dual IPEX-4 Lora Transceiver Module

Specifications SoC ESP32 C6 RISC V 32 bit high performance single core processor 160 MHz RISC V 32 bit low power single core processor 20 MHz Flash 16 MBWi Fi 2 4 GHz Wi Fi 6LoRa Chip SX1262LoRa Frequency 850 960 MHzLoRa Transmit Power Max Transmit Power 22 dBm Max Sensitivity 148 dBmAntenna Connector IPEX 4LNA SGM13005L4GPIO Leads 16x GPIO G9 G11 G8 G10 G2 G7 G4 G5 G6 G15 G16 G17 G18 G20 G21 G22 5x EXT IO Expansion PI4IOE5V6408 EXT P0 P4 Operating Power Supports DC 3 7 5V input via the BAT pin DC 3 3V input via the VDD 3V3 pinProduct Size SMD 18 0 x 15 0 x 2 3 mmProduct Weight 1 7 gIntroduction Stamp C6LoRa is a high performance programmable LoRa module designed for the 850 960 MHz frequency band Adopting SMD Surface Mount Device technology it features a compact and small form factor ideal for high density embedded integration The core of the module consists of an ESP32 C6 SoC an SX1262 LoRa RF chip and an LNA signal amplification chip Two onboard IPEX antenna connectors are provided for connecting external Wi Fi and LoRa antennas respectively The LoRa RF chip delivers a maximum transmit power of 22 dBm and a receive sensitivity of 148 dBm The ESP32 C6 main controller integrates abundant peripheral interface resources supporting secondary development for extended functions It also supports 2 4 GHz Wi Fi 6 unlocking more possibilities for IoT applications A PI4IOE5V6408 IO expansion chip is integrated internally to control
