UNI-T Thermal Camera Uti120Mobile Uti120Ms 120 × 90 Infrared Thermal Imager For Ios & Android Phone Thermal Imaging Came

Specifications Model UTi120 MobileIR Resolution 120 90 pixelsField of View FOV 50° 38°Thermal Sensitivity NETD 60mKTemperature Range 20°C to 400°CEmissivity Adjustable 0 1 0 99 Frame Rate 25 HzMeasurement Accuracy ±2°C or ±2 whichever is greater Display Modes Thermal imaging Blending combines image with mobile phone image Picture in picture PIP Image Capture Modes Photo or VideoColor Palettes Iron Red Rainbow Gray Scale Red Hot Black White High Contrast RainbowImage Format JPGData Communication Type C USBDrop Resistance 2 metersModel UTi120 MSInfrared Resolution 120 90Temperature Range 20°C to 400°COutput Frame Rate ≤ 25HzResponse Band 8 14μmDetector Pixel Size 17μmNETD Thermal Sensitivity 60mKField of View FOV 50° 38°Focus Mode Focus FreeMeasurement Functions Center point maximum temperature minimum temperatureAccuracy ± 2 or ± 2°C whichever is greater Units °C °FResolution 0 1°CEmissivity Settings Adjustable from 0 01 to 1 00Analysis Objects Point line circle rectangle up to six Color Palette 7 optionsImage Video Capture SupportedPicture in Picture Simultaneous display of phone camera and infrared images High and Low Temperature Tracking Real time tracking of thermal image s highest and lowest temperature points High and Low Temperature Alarm Customizable temperature thresholds for alerts Picture Editing Images can be edited after capture video editing is not supported Interface USB
