Felistick Fpv Vts Module Voltage Spike Suppressor Filtering Suppression Board With Solid State Capacitor Fpv Tvs Module

Note Size is manual measurement there are exist errors The FPV drone image transmission and others in picture shown will not include Description As is well known the horizontal stripes streaks snowflakes etc in analog image transmission are closely related to the ripple of the power supply and the wiring inside the aircraft When the voltage suddenly rises and reaches the conduction threshold of the TVS tube the TVS will instantly short circuit limiting the power supply voltage to 26V reducing the impact on the overall electrical equipment of the aircraft effectively suppressing the ripple horizontal stripes peak voltage etc of the simulation system and improving the stability of the entire system Capacitors mainly play a filtering role At the moment when the battery voltage drops capacitors will discharge to the main power supply which is equivalent to two small batteries connected in parallel Conversely when the power supply voltage rises capacitors charge With each discharge and charge the voltage fluctuations of the power supply are filtered out Specification Brand FeliStickItem Name FPV VTS Module Voltage Spike Suppression Filtering ModuleBoard Type Short Version Long VersionUsed for RC FPV DronePurpose of TVS filtering module 1 Filtering and voltage spike suppression2 Minimize the damage to components caused by the reverse electromotive force of the motor minimizing the damage to the flight control and ESC 3 Minimize the distance b
