SDS824X-HD Digital Oscilloscope 4 Channel 200Mhz Siglent 7'' Wave Generator 2Gsa/S 12 Bit High Resolution Lab Oscillosco

Specifications Model SDS824X HDBandwidth 200 MHz Analog Channels 4Vertical Resolution 12 bitMax Sample Rate 2 GSa s 1 channel 1 GSa s 2 channels 500 MSa s 4 channels Memory Depth Up to 100 Mpts ch 1 channel 50 Mpts ch 2 channels 25 Mpts ch 4 channels Waveform Capture Rate 120 000 wfm s Normal 500 000 wfm sTrigger Types 14 types including Edge Pulse Video Serial and Setup HoldSerial Protocol Support I²C SPI UART CAN LIN Standard Display 7 inch TFT LCD capacitive touchscreen 1024 600 resolution Features ① High Resolution Touchscreen DisplayThe 7 inch capacitive touchscreen 1024 600 offers intuitive navigation and crisp waveform visualization The 12 bit vertical resolution ensures precise signal detail ideal for analyzing low amplitude or high frequency signals in lab environments ② Advanced Triggering and Protocol AnalysisWith 14 trigger types and built in support for decoding I²C SPI UART CAN and LIN protocols this oscilloscope simplifies debugging complex systems The serial trigger feature accelerates fault detection in embedded designs ③ Ultra Fast Waveform CaptureAchieve up to 500 000 waveforms per second in Sequencemode capturing elusive signal anomalies with unmatched efficiency The deep memory 100 Mpts ch retains long duration signals without compromising detail ④ Expandable FunctionalityAdd 16 digital channels optional for mixed signal analysis or integrate the USB AWG module to generate custom wave
