Lilygo T-Display C5 Development Board ESP32-C5 Core Dual Band Wifi6 BLE5 High Performance Type-C Port Iot Development Mo

Specification Brand LILYGOProduct Name T Display C5 Development BoardMCU ESP32 C5 WROOM 1UDual band Wi Fi 6 2 4 GHz5 GHz IEEE 802 11 ax b g nBluetooth BLE 5Flash 16MB PSRAM 8MBDisplay 1 9 ST7789 IPS LCDResolution 170 x 320 pixelsRGB565 color 4 wire SPI interfaceWorking voltage 3 3VPowerBattery USB Type C input 5V 500mAOnboard BMU Battery Management Unit AXP2602JST GH 1 25mm battery connectorInterfaceI O GPIO pins UART TXD RXD I²C SDA SCL SPI MOSI SCK Qwiic JST SH 4 Pin connectorBOOT and RESET buttonsDimensionsWeight Size 62 x 26 x 10 mmWeight about 14 1gFeatures 1 Integrated 1 9 full color IPS screen for real time data display and UI projects 2 ESP32 C5 core with dual band Wi Fi 6 and BLE 5 for high speed wireless communication 3 16MB Flash 8MB PSRAM suitable for complex applications and graphic interfaces 4 Onboard AXP2602 BMU supports battery power management and low power operation 5 USB Type C port for programming power supply and easy connection to PC 6 Rich GPIO and Qwiic connector for quick expansion with sensors and modules Package Includes 1 x LILYGO® T Display C5 Development Board2 x Pin Header Strips1 x Power Cable 1 x 2 4G 5G WiFi Antenna
